TESCOM 26-1017-14-005 Pressure Reducing Regulator 5-500 PSIG – Brass

In stock

Applications:

  • Test equipment
  • Calibration stands
  • Production equipment

Features:

  • Can be easily converted to seven different outlet pressure ranges
  • Numerous inlet and outlet porting options
  • Unbalanced stem provides positive shut-off
  • Safety and reliability of piston sensor
  • Excellent sensitivity through a wide range of pressure settings
  • Vents to zero psig / bar in all pressure ranges

Specifications:

  • Maximum Inlet Pressure Brass: 6,000 PSIG (415 bar)
  • Maximum Outlet Pressure: 5-500 PSIG (0.3-35 bar)
  • Design Proof Pressure: 150% maximum rated
  • Leakage: Bubble-tight
  • Flow Capacity Standard: Cv = 0.06
  • Inlet & Outlet Port Type: SAE
  • Inlet & Outlet Port Size: 1/4 inch
  • Modification: Viton-A® O-rings with gauge ports
  • Operating Temperature: -40°F to 165°F (-40°C to 74°C)

Media Contact Materials:

  • Body Materials: Brass
  • Bonnet: 300 Series Stainless Steel
  • 40 Micron Filter: Bronze
  • Seat Main Valve: Vespel®
  • Seat Vent Valve: CTFE
  • Seals: Buna-N
  • Back-Up Rings: Teflon®
  • Trim: 300 Series Stainless Steel

Other:

  • Cleaning: CGA 4.1 and ASTM G93
  • Weight (without gauges): 5.7 lbs. / 2.6 kg
Brands:
SKU: 26-1017-14-005

Tescom 26-1017-14-005 controls pressures up to 6,000 psig / 415 bar. This pressure reducing regulator offers standard venting providing decreased outlet pressure. The Tescom 26-1017-14-005 has an interchangeable spring and sensor for product versatility. The low torque hand knob is easy to adjust.
